HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin High Frequency Welding Machine of Truck Cover_Oil Booms_Tensile HF Welding

Short Description:

HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin 01: Application HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin is popular used for flexible products made of PVC,PU,TPU, applied for air, water tight seam sealing, targeted for storage, screen shield, covering, signing and advertising Advertising signs, and large format billboards Small and large format technical textile PVC or PU coated Tensile structures, tents, shade systems, truck covers and side contains Swimming pool liners and co...


  • Model: KLR-5KW-SN
  • HF Power: 5000w
  • Electrode Size: 600*250mm
  • Gross Weight: 650kgs
  • Packaging Volume: 3.5CBM
  • Product Detail

    Tech

    Product Tags

    HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin

    01: Application

    HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin is popular used for flexible products made of PVC,PU,TPU, applied for air, water tight seam sealing, targeted for storage, screen shield, covering, signing and advertising

    Advertising signs, and large format billboards

    Small and large format technical textile PVC or PU coated

    Tensile structures, tents, shade systems, truck covers and side contains

    Swimming pool liners and covers, oil booms, flood dams and water tanks

    Airport hangars, portable storage structures, containment pools, ground liners

    02: Parameter

    Name HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin
    Model KLR-5KW-SN
    HF Power 5000W
    Input Power 8KVA
    Heating Power 500~1000w
    Power Supply 220V/350V, 50Hz/60Hz
    Electrode size 600*250mm
    Stroke Distance 150~200mm
    Spark detective device NL-5557
    Oscillator tube 7T85RB
    Welding Pressure 300~500w
    Welding Time 1~5 Seconds
    Net Weight 600kgs
    Gross Weight 650kgs
    Packing Dimension 130*111*212cm

    03: Advantages

    Welding current limit meter read in tuning basing on auto base

    NL-5557 Anti-sparkle device to protect the machine for overload

    Curved HF electrode is available for sealing round window profile

    frame rolled steel structure for excellent strength and work ergonomic

    Equipped with laser scan light to guide the seam line in overlap process

    With deep and wide trough behind the electrode for material storage and handling

    Manual and auto model optional for convenient debugging, maintenance and operation

    Heating device with thermostat concerned in HF impulsing seam is additional function

    Smooth glide wheel for each movement in-ground welded fabric or relocation desired place

    HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin is optional configuration in #1: HF Power #2: Trough Depth #3: Throat Depth #4: Dimension of Electrode #5: Stroke Distance

    https://www.hfwelds.com/products/canvastarpaulintent-hf-welding/


  • Previous:
  • Next:

  • HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin

    Tech Support

    In order to preserve the longevity of HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin, maintenance is key, when a HF welder goes down, there can be serious ramification such as halts in productivity leading to a loss in profit, this is way KEEPLEADER has created a checklist that outline the preventative measures you can take on a daily to a yearly basis to ensure that HF welder is running smoothly, as a disclaimer, before any maintenance is carried out ensure that it is in a safe condition and that services are switched off and isolated, always short capacitors and components to earth before touching, our HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin has main power switch, and separated power switch on operation panel, if want enter inside to repair or maintenance, must close the main power switch, and close the input power source, which is for double safe consideration, never use wet or oil rags when cleaning HF welder, instead use denatured alcohol, below you will find a tried and true outline for HF welder maintenance

    Daily Maintenance

    Wipe the table down every morning

    Keep the area around the HF welder clean from debris

    Inspect the electrode bar for cleaning without melting residues

    Listen the oscillator cooling fan is working

    Inspect any visible damage outside

    Lubricate the mechanical parts

    Monthly Maintenance

    Inspect the earth connection platen

    Inspect the pneumatic supply

    Inspect the power wire and components are connected without any loose

    Periodic Maintenance

    Heating element, thermostat

    Parallel electrode holder and platen

    Ensure earth connection are in good condition

    Check for cracks or discoloration

    Yearly Maintenance

    Remove all panels and clean inside of the machine

    Inspect the wire earth connection (replace if damaged)

    Inspect electrode and earth platen (replace if damaged)

    Inspect air pressure regulator for leaks

    Clean interior of generator cabinet

    KEEPLEADER also offers a comprehensive preventative maintenance program that includes adjustments to the HF Welder Heat Sealer for PVC Tent Canvas Tarpaulin, cleaning of surfaces, enhanced training on specific applications and customized manual for ongoing maintenance, if you have any questions about our maintenance programs, you can contact our tech staffs to learn more
