Small Vacuum Forming Machine of Blister Vacuum Thermoforming of Blister Vacuum Thermoforming machine of plastic cylinder box lid_cover making machine
|
Small Vacuum Forming Machine of Blister Vacuum Thermoforming |
|
|
Mainly application |
|
| This machine is used for thermoform all kinds of shapes, in the blister packing of toys, hardware, foodstuffs and electronic products | |
|
Character |
|
| Mini style, save cost and space
Compacted shape, which is for convenient transportation Easy and convenient operation and maintenance Sheet by sheet feeding manually, which is for saving cost Automatic output Easy operation, just need of manual loading material Heating element is separated control, by which to keep the temperature even Automatic roller feeding is available (under request) Laser positioningMini style, save cost and space Compacted shape, which is for convenient transportation Easy and convenient operation and maintenance Sheet by sheet feeding manually, which is for saving cost Automatic output Easy operation, just need of manual loading material Heating element is separated control, by which to keep the temperature even Automatic roller feeding is available (under request) Laser positioning |
|
|
Mainly parameter |
|
| Model: | KLY-610/560 |
| Forming length | 610mm |
| Forming width | 560mm |
| Forming height | 150mm |
| Bottom mould stroke | 200mm |
| Suitable sheets | 610mm |
| Productivity | 100~300 times/hour |
| Heating power | 500W*25 |
| Temperature control | Separated infrared electronic control for each |
| Vacuum pump | 25m²H |
| Consumable power | 6–12.5KW(MAX) |
| Power supply | AC380V 50/60Hz |
| Air compressor | 3HP |
| Overall dimension | (L)2750mm*(W)2100mm*(H)2100mm |
| Net weight | 1000Kg |
pls contact KEEPLEADER for more info and tech assistance about Small Vacuum Forming Machine of Blister Vacuum Thermoforming
Small Vacuum Forming Machine of Blister Vacuum Thermoforming is used for PVC, PET, PS, Blister packages thermoforming, maximum workable size is customized
